FoxESS T8_G3 Grid-Tied Inverter (8 kW, 3-Phase)

The FoxESS T8_G3 3-phase grid-tied inverter is a device with a rated power of 8000 W, equipped with two independent MPPTs and a built-in DC switch. The inverter features a maximum efficiency of 98.6% and a low start-up voltage of 140 V.

The FoxESS T8_G3 inverter from the T series is designed for 3-phase residential installations and small commercial systems. The device has an IP65 protection rating, which allows for safe outdoor installation. Communication is carried out via the included WLAN module, allowing for remote monitoring of operating parameters through a dedicated app. Integrated AFCI protection and Type II surge protection for both DC and AC sides increase the safety level of the entire installation.

Key features

• Maximum efficiency up to 98.6%
• Dual MPPT with a wide voltage range from 140 V to 1000 V
• Built-in AC/DC surge protection and AFCI protection
• Standard WLAN communication with remote monitoring capability
• 12-year manufacturer's warranty

Technical data

Rated output power	8000 W
Number of phases	3
Maximum DC voltage	1100 V
Start-up voltage	140 V
Number of MPPTs	2
Maximum input current (input A/B)	14 A / 14 A
Maximum AC current	12.8 A
Maximum efficiency	98.6%
Dimensions (W x H x D)	480 x 370 x 183.5 mm
Weight	17 kg
Protection rating	IP65
