JA Solar JAM60D41-500/LB Solar Module (500 W, N-type)

The JA Solar JAM60D41-500/LB solar module is a bifacial double-glass panel with a 500 W STC power output, based on half-cut cells in N-type 16BB technology. The product features an efficiency of 22.6% and withstands a front static load of up to 5400 Pa.

The JA Solar JAM60D41-500/LB solar panel was designed using N-type technology and Bycium+ 16BB cells. The use of 2.0 mm double glass on both sides of the module increases its durability and enables bifacial energy generation. The black frame design in the Full Black variant provides a uniform, dark appearance for rooftop installations. The module comes with a 15-year product warranty and a 30-year linear power output warranty.

Key features

• Bifacial double-glass design (Double Glass Bifacial)
• Uses 182 mm N-type half-cut cells
• Low power degradation: 1 % in the first year and 0.4 % annually in subsequent years
• Maximum power temperature coefficient of -0.290 %/°C
• Integrated IP68 rated junction box with three diodes

Technical specifications

Maximum power (STC)	500 W
Module efficiency	22.6 %
Cell type	Monocrystalline, half-cut (120 pieces)
Dimensions	1953 x 1134 x 30 mm
Weight	27.3 kg
Open-circuit voltage (Voc)	43.85 V
Short-circuit current (Isc)	14.42 A
Connectors	MC4-EVO2A
Cable cross-section	4 mm²
Cable length	1200 mm
Maximum series fuse rating	30 A
